Wire And Cable Machinery Thailand Parallel Cable Manufacturing Machine
Flat twin-cord wire: twin cores, 3 cores , PVC insulated single or multiple copper conductors, sheathed with PVC layers.
1.Construction : Solid Bare Copper Conductor or copper wire stranded , PVC Insulated ( yellow + green , black , white etc )
A. bare copper conductor stranded :
Suitable for above seven strand of the silver jacketed wire, tinned wire, enameled wire, bare copper wire, copper-clad steel, copper cladding aluminum .
2. PVC insulated --- 80 +35 cable extrusion machine
Application : Suit for PVC /PE plastic extrusion , maily used in fire alam cable , electrical wire , house wire , data cable , network cable etc insulation
machine devices as reference
1.Magnetic Power Tension Pay Off stand
1. double head tension pay off stand
2. Dancer / straigter
3. 80mm Main extruder
4. Automated loader & dryer
5. Auto central Crosshead
6. Single /Double layer Moving trough
7. Main cooling trough
8. Water wiper
9. Digital Diameter controller
10. Mark printer( selectable )
11. Accumulator
12. Capstan
13.15KV Spark tester
14. Meter counter
15. Dual shaft type Take up
16. Master control cabinet
17.35 strip extruder machine
| Model: | HOOHA-80+35 | | Consisting Components |
| Pay off bobbin size: | 400-630 mm | | Pay off stand | 1 |
| Screw size: | 80mm | | Dancer | 1 |
| Motor control: | 30 kw inverter | | 80mm extruder | 1 |
| Screw speed: | 110 rpm | | loader & dryer | 1 |
| Output capacity: | 210 kg/hr | | Crosshead | 1 |
| Max. accumulating length | 200 m | | Moving trough | 1 |
| Finished cable diameter | 2.0---20.0 mm | | Main cooling trough | 1 |
| Max. line speed: | 200 m/min | | Water wiper | 1 |
| | | | Diameter controller | 1 |
| | | | Mark printer | 1 |
| | | | Accumulator | 1 |
| | | | Capstan | 1 |
| | | | Spark tester | 1 |
| | | | Meter counter | 1 |
| | | | Take up | 1 |
| | | | Control box | 1 |
